Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Light Black Headlight Film with Air Channel Paper Liner
Click to open expanded view
SKU: ELT01

Light Black Headlight Film with Air Channel Paper Liner

Price
$41.99

Width: 1ft(30cm)

Length: 32ft

How Much Vinyl Is Need To Wrap Different Type Of Vehicles

When you order vinyl wrap without knowing how much you need, you risk running short before finishing or wasting money on excess material. The exact amount depends on your car’s size, shape, and body style.

Most cars need 50–100 feet (15–30 meters) of vinyl for a complete wrap. Compact hatchbacks use less material, while larger sedans and SUVs require more.

How Much Vinyl You Need - Quick Guide

The table below shows the average vinyl length needed to wrap common car types using a 60-inch (1.52 m) roll.

Car Type Vinyl Needed (Feet) Equivalent (Meters) Notes
Micro Car 25–30 ft 7–9 m Very small vehicles such as Smart Fortwo or Kei cars.
Mini Car 40–50 ft 12–15 m Compact city cars like the Mini Cooper or Fiat 500.
Compact / Small Hatchback 50–55 ft 15–17 m Popular models such as the Honda Fit or Toyota Yaris.
Coupe 50–60 ft 15–18 m Two-door vehicles with wider panels and sporty designs.
Mid-Size Sedan 60–65 ft 18–20 m Cars such as the Toyota Camry or Tesla Model 3.
Full-Size Sedan 65–80 ft 20–25 m Larger sedans with extended sides and roofs.
Hatchback 55–65 ft 17–20 m Compact models with rear hatches, e.g., VW Golf, Civic Hatchback.
Wagon 60–75 ft 18–23 m Longer body designs with extended rear sections.
Sports Car 55–75 ft 17–23 m Low, wide cars with complex curves and flared fenders.
Small SUV / Crossover 65–80 ft 20–25 m Compact SUVs with moderate height and curved body panels.
Large SUV / 4WD 80–100 ft 25–30 m Higher body panels and larger bumpers; requires more vinyl.
Pickup Truck 75–90 ft 23–27 m Includes tailgate, bed sides, and wheel arches.
Van 90–110 ft 27–33 m Large, flat panels ideal for commercial and branding wraps.


Pro Tip: Always order 10–20% extra vinyl to allow for overlaps, stretching, and trimming, especially if you’re wrapping at home or working with curved panels.

How Much Vinyl Is Need To Wrap Different Type Of Vehicles

Partial Wraps

A partial wrap covers only selected areas of a car instead of the entire surface. Common choices include the hood, roof, trunk, bumpers, mirrors, or side stripes. Partial wraps are ideal if you want to add custom accents, branding, or a two-tone finish without committing to a full wrap.

On average, a partial wrap uses about 30–50% of the material needed for a full wrap. That means you’ll typically need 20–50 feet (6–15 meters) of vinyl, depending on your car’s size and the number of panels you choose to wrap. Always measure each section carefully and add a small margin for trimming and alignment to avoid running short.

How Much Vinyl Is Need To Wrap Different Type Of Vehicles

Factors That Affect Vinyl Usage

The numbers above give reliable estimates, but your exact vinyl needs can vary. Several factors influence how much material you should order:

  • Car Size and Design: Larger cars and vehicles with complex body lines require more vinyl. Curved panels, wide bumpers, and detailed edges increase surface area and trimming needs.
  • Wrap Type: A full wrap covers every painted surface, while a partial wrap only includes select areas such as the hood, roof, or accents. Naturally, partial wraps use less material.
  • Film Finish and Stretch: Different vinyl finishes vary in flexibility. Textured, metallic, and carbon-fiber wraps are thicker and less stretchable, which may increase waste during application.
  • Installer Skill: Professional installers use vinyl efficiently, while beginners should plan an additional 10–15% to allow for mistakes or trimming.
  • Body Accessories: Spoilers, mirrors, side skirts, and bumpers add extra surface area. Measure these parts separately to ensure full coverage.

How to Calculate Vinyl for Your Car

If you want a more precise estimate, use this simple method:

  1. Measure your car’s length and average height in meters.
  2. Multiply the two numbers to estimate total surface area.
  3. Divide the result by 1.52 (the standard roll width in meters).
  4. Add 10–20% for overlaps, curves, and trimming.

Example:
A sedan measuring 4.7 m long and 1.4 m high →
4.7 × 1.4 = 6.58 m² ÷ 1.52 ≈ 4.3 m of film per side.
Double that for both sides, then add the roof, hood, and bumpers for a total of about 18–20 meters.

Practical Tips for a Smooth Wrap

  • Choose high-quality vinyl. Premium brands like Vinyl Frog offer consistent thickness and reliable adhesive performance.
  • Prepare the workspace. Wrap in a clean, dust-free area to avoid bubbles and debris.
  • Plan before cutting. Lay out each panel to reduce waste and ensure precise alignment.
  • Allow curing time. Give the wrap 24–48 hours before washing or exposing it to extreme conditions.
Size Help
Out of stock

Share this product

Post Pin E-mail

Product Description

VinylFrog's Light Black Headlight film is a fantastic choice for car enthusiasts who appreciate personalization and meticulous attention to detail. These modifications do more than just elevate your vehicle's overall appearance; they also offer a host of practical advantages. If you're aiming for a sportier, sleeker look and want to enhance the longevity of your headlights, our Light Black Headlight film with Air Channel Paper Liner is the ideal solution.

Crafted from high-quality Polyvinyl Chloride (PVC), this sleek lining adds a customized touch to your car's aesthetics. It offers a visually appealing way to enhance the appearance of your vehicle's headlights. Its subtle yet stylish aesthetics add a touch of sophistication without sacrificing functionality. This film provides a balance between customization and practicality, allowing you to express your personal preference with flair.

But it's not just about looks. Our Light Black Headlight film serves as both a stylistic enhancement and a protective shield. It acts as a protective barrier against minor physical damage such as scratches, debris, and small rocks that might otherwise mar the surface of your headlights. It serves as an extra layer of defense against these external factors, reducing the likelihood of cracks or chips.

Features And Specifications

  • Durable and high performance.
  • Eco-friendly high-grade film.
  • Water and weatherproof.
  • Heat, UV, and scratch resistant.
  • Easy to apply and maintain.
  • Equipped with a protective liner.
  • Acrylic-based, Repositionable Ultra-Clear adhesive.
  • Easy to reposition and slide.
  • Equipped with air-release channels for bubble and crease-free installation.
  • Lifetime: 1 year (Based On Vertical Exposure)

Please Note: This light tint film is semi-transparent. The color may look slightly different on the white backing paper, but once the backing is removed and applied to your lights, you’ll see the true color.

Video

General Description

  • Features: Scratch Resistance, Protective Liner
  • Type: Automotive, Architectural, Marketing Applications, Indoor & Outdoor
  • Lifetime: 1 year (Based On Vertical Exposure)
  • Adhesive Type: Acrylic-Based, Repositionable Ultra-Clear adhesive.
  • Finish Color: Light Black
  • Application Method: On a clean, dry surface.

Proper Installation

If the headlight surface is clean and undamaged before installation, the wrap adheres evenly and removes smoothly.

Proper Removal Technique

Using gentle heat (like a heat gun or hairdryer) softens the adhesive, making it easier to peel without pulling or tearing the headlight’s factory coating.

Warning

If the headlights are already oxidized, yellowed, or have weak factory coating, peeling the wrap can pull off clear coat or cause flaking.

Physical Properties

Classification Unit Spec Remark
Thickness Top protected film um 25±5 PE
Acrylic Adhesive um 20±2

Solvent-based
Face Film um 100±5 /

Release liner

 um 180±2%  Paper Liner
Surface

-

 - Glossy & Matte /
Width

-

 cm 30/40±0.01% 1ft/1.3ft
Length

-

 m 10±1% 32ft


Physical Performance

Features Test Method Results
Gloss (60°) GB 8807 92.3
VLT / 87%
Self-healing Layer Elongation at Break GB/T 1040.1 112
Face Film Elongation at Break GB/T 1040.1 309.5
Tear Strength GB/T529 92.7 KN/m
Tensile Strength GB/T 1040.1 21.6 Mpa
100% Modulus GB/T 1040.1 9.1 Mpa
Anti-yellowing / ΔE< 1.2
Light Transmission ＞40% 43%
Adhesive residue / ＜3%
Release force (N/25mm) paste on steel board, 90° 26℃ and 60%, GB2792 0.16
Initial tack (g/25mm) under 24℃ and 26%, GB31125-2014 860
Peel Strength (N/25mm) 180° 15
Holding power(h) paste on steel board, hang on by 25mm*25mm*1kg weight under 29℃ and 55%, GB/T4851-1998 No peel off within 48 hours
Aging Test  65℃ and 7 days No adhesive residue under 20 times wrapping
Application Temperature / +20℃ to +30℃
Service Temperature / -50℃ to +110℃
Recommended Shelf Life 72°F (22°C) and 50% RH 1 year
Durability / 1 year
Time limits Must use it within 3 months after receiving the wrap film 3 months



But it's not just about looks. Our Light Black Headlight film serves as both a stylistic enhancement and a protective shield. It acts as a protective barrier against minor physical damage such as scratches, debris, and small rocks that might otherwise mar the surface of your headlights. It serves as an extra layer of defense against these external factors, reducing the likelihood of cracks or chips.

What sets this film apart is its superior temperature and UV resistance. It acts as a barrier against the harmful effects of ultraviolet rays from the sun. Over time, UV radiation can cause headlights to yellow, become foggy, or fade. By applying headlight film, you create a shield that helps to mitigate these effects, preserving the clarity and longevity of your headlights. It also prevents oxidation, a common cause of deterioration, reducing the need for costly repairs over time.

Moreover, the Air Channel Paper Liner is a noteworthy addition. It streamlines the installation process by preventing air bubbles, ensuring a smooth and professional finish. This innovative feature simplifies headlight filming, saves time, and resources, and enhances the longevity of the film, making it accessible and hassle-free for both professional installers and DIY enthusiasts.

But the benefits don't stop there. filmed headlights provide a more focused and precise beam of light, significantly improving your ability to spot and respond to potential road hazards. They also reduce glare and reflection, particularly valuable in adverse weather conditions like rain or fog, guaranteeing better visibility.

Enhanced contrast and sharpness are additional perks. filming amplifies the difference in brightness between lit areas and darkness, aiding in the recognition of objects such as pedestrians and road hazards. Improved image clarity, especially in low-light conditions, ensures better visibility on poorly-lit roads.

In conclusion, VinylFrog's Light Black Headlight film with Air Channel Paper Liner offers both style and practicality for your vehicle. With its unique blend of aesthetics and protection, this film not only enhances your car's appearance but also safeguards your headlights and improves your driving experience. Its Air Channel Paper Liner ensures a smooth installation process, making it a valuable addition to any car enthusiast's customization efforts.

Shelf Life

1 year from date of purchase when stored at 50°F to 80°F (15°C – 25°C) and 45% to 50% relative humidity. Optimum recommended storage conditions are 72°F (22°C) and 50% relative humidity.

Important Notice

The physical properties of the product detailed in this document are based on tests that we believe to be reliable. They are intended only as a source of information and are given without guarantee. They do not constitute a warranty. Purchasers should independently assess the suitability of this material for their specific use prior to application.

Warranty, Limited Remedy, and Disclaimer

Unless an additional warranty is specifically stated on the applicable product packaging or literature, VinylFrog warrants that each product meets the applicable specifications at the time of shipment. We make no other warranties or conditions, express or implied, including but not limited to any implied warranty or condition of merchantability or fitness for a particular purpose, or any implied warranty or condition arising out of a course of dealing, custom, or usage of trade. If the VinylFrog product does not conform to this warranty, then based on our discretion, the sole and exclusive remedy is either the replacement of the product or a refund of the purchase price.

Limitation of Liability

Except where prohibited by law, VinylFrog will not be liable for any loss or damage arising from its product, whether direct, indirect, special, incidental or consequential, regardless of the legal theory asserted, including warranty, contract, negligence or strict liability.

Durability

The durability of the product is based on exposure conditions in South China. Actual performance life will depend on substrate preparation, exposure conditions, and maintenance of the product. For instance, in areas with excessively high temperature, industrial pollution, or high altitude, exterior performance will decrease.

Recommendations

Recommended application tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, sprayer, towel, and installation liquid
Application method: Standard methods for Car Light Protection Film. Do not overstretch and overheat. Post heating is necessary.
Post-heating temperature: 110°C flat surfaces, 130°C curves and overlaps.
Aftercare: PH neutral. Avoid wax or solvents.
